FOV expansion development kit

The FOV Development Kit features two imaging systems with a wide-angle objective for overview and a narrow-angle objective (50mm or 75mm) for high resolution in the area of interest. This development kit is accompanied with software to demonstrate its suitability for surveillance and inspection applications (face recognition, autofocus, area of interest selection).

The kit includes:

• Fast steering mirror, MR-E-3 head unit (DVIS)

• Mirror controller, MR-E-3 base unit

• Focus tunable lens, EL-16-40-TC-VIS-5D with embedded controller ECC-1C

• 2x Industrial camera, Daheng MER2-302-56U3C

• Wide-angle objective, 4 mm

• Narrow-angle objective, 50 mm or 75 mm

• USB to UART cable, Hirose connector, 1 m long

• 2x USB3 cable, 3 m long

• Black anodized aluminium mounting set

• Aluminium case
